Blustream HEX18G-KIT HDBaseT Extender Kit - Uncompressed HDMI 2.0 4K 60Hz 4:4:4 - Bi-directional IR & HDCP 2.2 - 100m

HEX18G-KIT - Overview

• Features:

  • Advanced HDBaseT technology offering distribution of video and audio over a single CAT cable
  • Supports uncompressed HDMI2.0 18Gbps specification including HDR
  • Supports 4K 60Hz 4:4:4 UHD video
  • Supports HDMI video distribution up to 100m
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • HDMI re-clocking on the HDBaseT Receiver to help solve HDMI HDCP, compatibility and handshaking issues
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • Bi-directional IR & RS-232 pass through
  • Supplied with Blustream IR receiver and emitter
  • Bi-directional PoC (Power over Cable) to power extenders from either transmitter or receiver end
  • HDCP 2.2 support


• Specifications:

  • HEX18G Transmitter
  • Video Input Connectors: 1x HDMI Type A, female
  • Video Output Connectors: 1x HDBaseT™ RJ45 connector
  • IR Input ports: 1x 3.5mm stereo jack
  • IR Output ports: 1x 3.5mm mono jack
  • RS-232 serial port: 1x 3-pin Pheonix connector
  • Power Supply: 1x 24V/1A DC

    HEX18G Receiver
  • Video Input Connectors: 1x HDBaseT™ RJ45 connector
  • Video Output Connectors: 1x HDMI Type A, female
  • IR Input ports: 1x 3.5mm stereo jack
  • IR Output ports: 1x 3.5mm mono jack
  • RS-232 serial port: 1x 3-pin Pheonix connector
  • Power Supply: 1x 24V/1A DC


  • Casing Dimensions (WxDxH): 3.74" x 4.56" x 1"
  • Dimensions Including Connections (WxDxH): 3.74" x 4.56" x 1"
  • Shipping Weight (Kit): 3.4lbs
  • Operating Temperature: 32°F - 104°F
  • Storage Temperature: -4°F - 140°F
  • Power Supply: 1x 24V/1.25A DC


• Item Includes:

  • 1x HEX18G-TX Transmitter
  • 1x HEX18G-RX Receiver
  • 1x 24V/1.25A DC power supply
  • 1x IRE1 receiver
  • 1x IRR emitter
  • 2x Mounting brackets
  • 1x Quick Reference Guide


• Warranty:

  • 3 Year Warranty
