Blustream IP200UHD-TX IP Multicast HDMI UHD Video KVM over 1GB Network Transmitter w/ Bi-directional IR / RS-232 & USB

IP200UHD-TX - Overview

• Features:

  • Advanced UHD video over 1Gb Network
  • Virtually unlimited system size
  • Extends HDMI up to a distance of 100m over a single CAT cable
  • Supports up to 4K HDR UHD video sources (3840 x 2160 @ 30Hz 4:4:4, 4096 x 2160 @ 24Hz 4:4:4, and 4K @ 60Hz 4:2:0)
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio transmission
  • Advanced signal management for independent routing of IR, RS-232, USB/KVM, audio and video
  • PoE (Power over Ethernet) to power Blustream products from PoE switch
  • HDCP2.2 compliant with advanced EDID management
  • Analog L/R audio embedding
  • Analog L/R audio breakout
  • Local 24-56V power supply (should Ethernet switch not support PoE) - sold separately
  • Features 4 operational modes:
  • - Matrix distribution (requires 1Gb network switch)
  • - Video wall (requires 1Gb network switch)
  • - One-to-one HDMI extender (no network switch required)
  • - One-to-many HDMI extender (no network switch required)


• Specifications:

  • Video input: 1 x HDMI Type A, female
  • Video output: 1 x LAN RJ45 connector
  • Audio input:1 x 3.5mm L/R Analog audio
  • Audio output connectors: 2 x RCA L/R Analog audio
  • Ethernet port: 1 x LAN RJ45 connector
  • RS-232 Serial port: 1 x 3-Pin Phoenix connector
  • USB/KVM Port: 1 x USB - Type B
  • IR input: 1 x 3.5mm stereo jack
  • IR output: 1 x 3.5mm mono jack
  • Firmware Update: 1 x Micro-USB
  • Dimensions (W x D x H ): 190mm x 114mm x 25mm
  • Shipping Weight: 0.8kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)


• Item Includes:

  • 1x IP200UHD-TX
  • 1x (IRR) IR Receiver
  • 1x (IR1) IR Transmitter
  • 1x Serial 3-pin Phoenix Connector
  • 1x Mounting Kit


• Warranty:

  • 3 Year Warranty


• GTIN:

  9340242002907
