Bolin D2-210H Dante AV-H H.264 AV-over-IP PTZ FHD Camera with 10x Zoom - HDMI/IP/USB2.0 - 12VDC/POE+ - Black

D2-210H - Overview

• Features:

  • High-Quality Imaging - Full HD: Bolin's Dante AV-H™ PTZ cameras are equipped with Sony sensor to provide brilliant, high-quality images in 1080p60 resolutions with 10x optical zoom.
  • Video Output: Deliver Dante AV-H™ version IP streaming video to the Dante network, and local HDMI video and USB streaming output to conventional workflows in FHD.
  • Multicast Mode: Point to Multipoint and Point-to-Point Distribution - supports both unicast and multicast video distribution.
  • Video Settings: Image parameter adjustments include exposure, focus, iris, shutter speed, white balance, gamma, wide dynamic range, image stabilizer, flip/mirror, and more with configurable video settings.
  • Audio: HDMI/SDI/USB embedded high-quality audio and Dante AV™ video streaming embedded audio with support for Mic-in and Line-in audio input. The audio that is input to the camera can be routed within a Dante audio over IP system.
  • PTZ Movement: Extremely quiet and smooth operation for Pan/Tilt movements combined with enhanced adaptive, variable, and super slow speed control provides accurate and effective operation experiences. Picture Profile Preset- Image parameter setting restore with presets and quick access operation.
  • Ease of Installation and Use: Simply connect one network cable from camera to any 1GB Ethernet network/POE device to access to existing Dante Audio-Over-IP system.
  • Always Up to Date: Firmware updates, upgrade via USB and IP interface to keep Dante AV-H camera features and performance up to date.


• Specifications:

  • Image Sensor: Sony Progressive scan CMOS image sensor 1/2.8 type
  • Number of effective pixels: 1920X1080, 2.13 Megapixels
  • Zoom: Optical Zoom 10X, Digital Zoom 16X
  • Focal Length: f= 4.34 mm (Wide) to 35.17 mm (Tele)
  • Aperture: F1.85 (Wide) to F2.63 (Tele)
  • Horizontal Angle of View: 68.8°(W)~8.8° (T)
  • Vertical Angle of View: 39.5° (W)~5.1° (T)
  • Min. object distance: 10mm (Wide)
  • Min. Illumination: 0.5lux(color),0.1lux(black)
  • Shutter Speed: 1/1 sec to 1/10000 sec (22 steps)
  • Focus: Auto, Manual, One Push
  • White Balance: Auto, Indoor, Outdoor,OPW,ATW, Manual
  • Exposure: Auto, Manual, Shutter /Iris /Brightness priority
  • Image Adjustment: Brightness, Color(Saturation), Contrast, Sharpness, HUE
  • Back Light Compensation: On/Off
  • E-Flip: On/Off
  • WDR: On/Off
  • Mirror: Horizontal
  • Day/Night: On/Off
  • Contrast: Yes
  • Color Gain: Yes
  • Color Hue: Yes
  • Color Matrix: Yes
  • Gamma: Yes, 0-4
  • High Sensitivity: Yes
  • Sence: Default, Clear, Bright, Soft
  • Focus Zone: Face Priority, All Area, Uper Area, Central Area, Lower Area
  • AI Face Detection Focus: Yes
  • AI Face Auto Exposure: Yes
  • Noise Reduction: 2D/3D, 1-255
  • S/N Ratio: ≥50db
  • OSD: Editable


• Item Includes:

  • 1x Camera
  • 1x IR Remote Controller (2x AA batteries required)
  • 1x Camera Power Adapter
  • 3x Camera Power Cord (1x US, 1x EU, 1x UK)
  • 1x HDMI Cable Secure Mount
  • 1x Bag of Mounting Screws
  • 1x RJ45 to RS232 Extension Cable
  • 1x RJ45 to RS432 Extension Cable
  • 1x Welcome Card


• Warranty:

  • 2 years
