Digital Forecast Bridge Mini 1000 SD-6 3G/HD/SD SDI & ASI 1x6 Video Distribution Amplifier with Reclocking

ITEM #: DF-BRIDGE1000SD6 MFG #: BRIDGE1000 SD-6

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
DIGITAL FORECAST
Free Shipping with $49 Minimum Order

List Price:

$220.00

Our Price:

$209.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

BRIDGE1000 SD-6 - Overview

Bridge1000 SD-6 distributes SDI SMPTE standard signals utilizing a single input to producte 6 outputs. The unit supports up to 1080P60 format. Its built-in reclocker and equalizer allows it to be used as as a signal repeater.

  • Features:

    • SDI distribution amplifier
    • Built-in cable equalizer & re-clocker
    • Up to 100 meter distances HD, up to 60 meters 3G-HD
    • 1 SDI input ( SD/HD/3G ) / ASI
    • 6 SDI out ( SD/HD/3G ) / ASI
    • 12V DC Power supply


  • Specifications:

    • Supports HDMI v1 .3
    • Supports multi-rate SDI formats
    • SMPTE 125M: NTSC (480i 59.94), PAL (576i 50)
    • SMPTE 296M: 720p (60/59.94/50)
    • SMPTE-274M,SMPTE-292M: 1080i (60/59.94/50) (1080p (30/29.97/25/24/23.98)
    • SMPTE-424M: 1080p (60/59.94) 3G


  • Item Includes:

    • Power Adaptor


  • Warranty:

    • 2 Years


  • GTIN:

    0704006295230
