JBL SRX910LA Dual 10-inch Powered Line Array 2-Way Loudspeaker - 105-degree

ITEM #: JBL-SRX910LA MFG #: SRX910LA

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$5,350.00

Our Price:

$3,729.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


SRX910LA - Overview

Dual 10-inch Powered Line Array Loudspeaker
The SRX900 Series embodies the advanced performance principles that drive JBL's development of audio products that make a real difference in the world of professional audio. This next-generation family of powered line arrays and subwoofers addresses the growing need for scalable small and medium-format professional sound-reinforcement solutions for rental companies, fixed installations and musicians seeking the ultimate combination of performance and portability.

The SRX910LA is a two-way active line array element that can cover a variety of mid to large-sized applications, including rental houses, touring artists, DJs, and installations. Built-in DSP and amplification offer a plug and play experience while providing consistency and optimum performance anywhere in the world.

JBL transducers and a new acoustic design provide excellent sound fidelity and best-in-class maximum SPL. The product features dual 10-inch neodymium Differential Driver woofers and a three-inch compression driver. The computer-optimized enclosure is made out of composite material and offers excellent performance while remaining compact and lightweight.

An innovative three-point rigging system and a full set of accessories allow systems to scale and solve the diverse needs of production companies and installation houses. JBL Performance is a new, full-featured software package that gives users control of the system on various platforms, including Windows, macOS, and iPad OS.

  • Features:

    • High-performance, high-density system solution in a truck-pack friendly format
    • High-power-handling transducers deliver low distortion, high fidelity, and class-leading output
    • Built-in, passively cooled Class D amplification with a universal power supply
    • Dual Ethernet ports with Neutrik etherCON connectors
    • Supports HARMAN HControl Ethernet
    • User-controllable DSP
    • LevelMax limiting uses sophisticated excursion-control algorithms to protect transducers
    • Rear-panel LCD provides complete access to control features
    • Reinforced composite loudspeaker enclosures
    • Innovative three-point rigging system

  • Specifications:

    • Frequency Range (-10dB): 53 Hz-19 kHz (array preset)
    • Coverage Pattern: 105 degrees nominal (400 Hz-16 kHz)
    • Maximum SPL: 135 dB
    • System Type: Line Array, two-way active
    • Amplifier Design: Class-D
    • Continuous Power Rating: 600 Watts | LF: 400 Watts | HF: 200 Watts
    • LF Driver: (2) JBL 261G-1, 10 in diameter, dual 2.0 in diameter voice coil, neodymium Differential Driver
    • HF Driver: (1) JBL 2432H-3, 1.5 in exit neodymium compression driver with 3 in voice coil
    • Enclosure: Polypropylene, aluminum baffle, plywood internal bracing, four integral recessed handholds
    • Inter-Enclosure Angles: 0.5, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12
    • Dimensions (H x W x D): 305 mm x 716 mm x 519 mm (12.0 in x 28.2 in x 20.5 in)
    • Net Weight (each): 26.7 kg (59 lbs)

  • Item Includes:

    • 1x SRX910LA
    • 1x Neutrik NAC3FX-W-TOP
    • 1x Neutrik NAC3MX-W-TOP

  • GTIN:

    0691991035685
