Jensen Iso-Max JT-6110K-B Ultra-high Performance 4:1 or 8:1 Step-down Line Input Transformer

JT-6110K-B - Overview

4:1 Stepdown for Balanced Bridging Inputs

• Features:

  • Jensen's highest level handling input transformer
  • Wide bandwidth: -3 dB at 0.15 Hz and 120 kHz
  • Recommended for levels up to +26 dBu at 20 Hz
  • High input impedance: 37.5 k Ohm
  • High common-mode rejection: 130 dB at 60 Hz


• Specifications:

  • Impedance Ratio:
  • 36k:2.2k / 10k:600


  • Turns Ratio:
  • 4:1


  • Max Input @ 20Hz:
  • +26dBu


  • THD @ 20Hz:
  • 0.009%


  • Freq Resp 20Hz / 20kHz:
  • -0.06dB / -0.08dB


• Item Includes:

  • JT-6110K-B Ultra-high Performance 4:1 or 8:1 Step-down Line Input Transformer


• Warranty:

  • For a period of 1 YEAR after purchase, Jensen Transformers, Inc. will, free of charge, repair or replace any part of an ISOMAX® product that fails due to defective materials or workmanship.
    For a period of 20 YEARS after purchase, Jensen Transformers, Inc. will, free of charge, repair or replace any Jensen OEM transformer or any Jensen tranformer contained in an ISOMAX® product that fails due to defective materials or workmanship.


• GTIN:

  0657248890018
