Small in size, huge in benefits
Building on Lab Gruppen's touring reputation for sonic excellence and rock-solid durability, E Series brings a competitive edge to the installation market by adding ultra-compact size, high operating efficiency, output configuration flexibility, and an unprecedented cost-benefit ratio.
At the heart of E Series is Lab Gruppen's IDEEA (IntelliDrive Energy Efficient Amplifier) technology. Based around a patented Class D variant output stage, IDEEA produces high power levels with very low distortion while drawing minimal mains current.
Lab Gruppen's proprietary Rail Sensing Limiter (RSLT), also exclusive to E Series, greatly reduces signal clipping to ensure high quality audio output at all times. User configurable for Hi-Z (70 V) or Lo-Z, RSL senses rail voltages and optimizes each output for instantaneous load conditions. RSL settings also facilitate asymmetric loading of the channels to optimize performance and efficiency. Total available output power can be allocated among the channels as required by the application. This makes it possible, for example, to drive a small sub on one channel, a number of 70 V ceiling loudspeakers on the second channel.
Lab Gruppen performance with Energy Star compliance
Lab Gruppen's IDEEA architecture secures full Energy Star compliance by combining net operating efficiency of greater than 80% with an auto-power-down feature. After 20 minutes with no input signal, the amplifier automatically switches to standby mode - with consumption of less than 1 W - and switches back on when an input signal returns. GPIO facilities enable third-party systems to remotely control and
monitor power state via contact closure.
Applications
Bars & restaurants
Retail outlets
Malls
Hotels & ballrooms
Conference centers
Museums & galleries
Houses of worship
Theme park installations
Educational establishments
Auditoriums
Performing arts centers
Convention centers
Transport hubs
