Luxi HD-28RD250 HDMI 28 AWG Raw Regular Wire - 250 Foot

ITEM #: LXL-HD-28RD250 MFG #: HD-28RD250

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the LXL-HD-28RD250

HD-28RD250 - Overview

The HD-28RD250 is a 250' (76 m) HDMI regular bulk wires for DIY field termination. This unit is HDMI 2.0 4k compliant thin and flexible. Can be pulled thru conduit easily and terminate with HDMI DIY connectors in the field. Can by cut to needed length. Spool in a box with usage log.

  • Features:

    • Simple and reliable HDMI field termination in 10 minutes
    • HDMI 2.0 4k, 32 audio ch., 1536 kHz sampling, dual video stream, multi audio stream, 21:9 aspect, dynamic AV sync, CEC extensions, 3D, HEAC compliance
    • Enabling the bulk wires to be pulled thru the wall
    • Enabling the bulk wires to be cut to length
    • Spool-in-a-box for easy wire handling

  • Specifications:

    • Jacket color and material: black matt PVC
    • Overall jacket diameter: 0.26 (6.5 mm)
    • HDMI specs: rev 1.4 Cat2 High Speed HEAC compatible
    • UL: pass UL-1581 VW-1; equivalent to IEC 60332-1; Jacket marking: Luxi High Speed HDMI Cable E119932 AWM; STYLE 20276 80°C 30V VW-1 CSA LL84201 CMG FT4
    • Supported formats: 4k, 3D, deep color, 1080p, etc
    • Max data rate: depends on cable length; 24 Gbps at 2 m
    • Max cable length: 12 m (40') at 1080p typical; up to 24 m (80') with Luxi HDMI Extender

  • Item Includes:

    • Bulk wires
    • Spool
    • Box

  • Warranty:

    • 3 years
