MuxLab 500444 4x4 4K/60 HDMI Matrix Switcher

500444 - Overview

• Features:

  • HDMI 2.0 supporting up to a 4K resolution at 60Hz (4:4:4) and 3D formats.
  • Deep Color supporting 10 & 12-bit.
  • Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby
  • Atmos, DTS-HD Master Audio and DTS:X
  • Allows any source to be displayed on multiple displays at the same time.
  • Allows any HDMI display to view any HDMI source at any time.
  • Each of the 4-input ports support independent EDID.
  • Supports Digital Audio output.
  • May be controlled via IP, RS-232, Handheld IR Remote and Front Panel Buttons.
  • Front-panel LCD display for status feedback.
  • HDMI connectors with Locking nuts.
  • Locking 2.1mm power connector.


• Specifications:

  • Video Bandwidth: 594MHz
  • Support Video Resolution: 480i,576i,480p,576p,720p,1080i,1080p@ 24/30/50/60Hz, 4K@30/60Hz and 3D formats

    Input Ports
  • Four (4) HDMI Receptacle
  • One (1) RS-232
  • One (1) Ethernet Port (Control)
  • One (1) IR Sensor 3.5mm Jack

    Output Ports
  • Four (4) HDMI Receptacle
  • Four (4) Digital Audio Output

    ESD Protection
  • Human-body Model:
  • ± 8kV (Air-gap discharge)
  • ± 4kV (Contact discharge)


  • Power Supply: One (1) 110-240V/12VDC/5A power supply with interchangeable blades
  • Dimensions: 17.20" x 1.69" x 8.86" (437mm x 43mm x 225mm)
  • Weight: 9.69lbs (4.40kg)
  • Chassis Material: Metal
  • Silkscreen Color: Black
  • Temperature & Humidity Operating: 0° to 40°C Storage: -20° to 85°C
  • Humidity: Up to 95% non-condensing
  • Power Consumption: 33W (max)
  • Compliance Regulatory: FCC, CE, RoHS


• Item Includes:

  • 1x HDMI 4x4 Matrix Switch, 4K/60
  • 1x 12V/5A DC power adapter
  • 1x Operation Manual
  • 1x Handheld IR Remote
  • 2x Mounting ears
  • 1x IR Sensor cable


• Warranty:

  • 2 Years


• GTIN:

  0663647920119
