Platinum Tools 106250 PoEplus 10Gig Shielded RJ45 Field Plug Cat7/ 6A/6

ITEM #: PLAT-106250 MFG #: 106250

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Platinum Tools, Inc.
Free Shipping with $49 Minimum Order

List Price:

$13.12

Our Price:

$11.15

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

106250 - Overview

The Platinum Tools 106250 PoE+ 10Gig Shielded RJ45 field installable plug optimizes throughput to to PoE+ powered devices. Compatible with a wide range of large cables with large conductors. Design facilitates field installation. Cast metal shell provides end to end shielding from extraneous noise interference in high band width applications.

  • Features:

    • HDBaseT PoE+ Compliant
    • Cat7, Cat 6A, Cat 6
    • No special crimp tools required
    • 50 micron gold plated contacts
    • Compatible with S/FTP or F/FTP Shielding
    • Solid or stranded conductors 26 - 23AWG


  • Specifications:

    • Compliance
    • ISO/IEC 11801
    • ANSI/TIA-568-C.2
    • ANSI/TIA568.2-D
    • IEEE 802.3an, 10GBit Suitable
    • UL and RoHS compliant

      Cable Compatibility
    • S/FTP or F/FTP Shielding
    • Stranded or Solid
    • 26AWG - 23AWG wires

      Insulation/conductor OD: .032" - .057" (8mm - 1.47mm)
    • Cable OD: .236" - .315" (6.0mm - 8.0mm)
    • Dimensions: 2.76 inch x 0.70 inch x 0.55 inch (70.20mm x 17.85mm x 14.0mm)


  • GTIN:

    0849160011194
