PreSonus StudioLive AR16C 16-Channel USB-C Hybrid Digital/Analog Performance Mixer

ITEM #: PRE-SLMAR16C MFG #: SLMAR16C

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

List Price:

$899.99

Our Price:

$699.99

After Savings:

$599.99

Availability: In Stock
iAvailability Description Popup
Presonus StudioLive AR16c Instant Savings!Save $100 when you order now. Hurry, when stock runs out, so will this offer!


SLMAR16C - Overview

Audio recording made easy.
Don't let the classic analog mixer design fool you - the PreSonus StudioLive® AR16c was built to record. With a pristine analog front-end, 12 high-gain XMAX mic preamps, and an 18x4 24-bit, 96 kHz, USB-C compatible USB 2.0 audio interface, its hybrid design makes it simple to record studio productions and mix live shows from a single intuitive console. Add in a musical 3-band analog EQ, mic/line boost for low-level vintage synths and broadcast microphones, all-new digital effects with rich reverbs and lush delays, Bluetooth® connectivity, and a stereo SD recorder..and you have a mixing and recording powerhouse that fulfills the needs of both modern musicians and content creators.

A full-featured audio interface.
The StudioLive AR16c audio interface operates at up to 96 kHz for high-definition mixing and recording. Record each of the 16 inputs, plus the main mix for even more flexible recording options. Play back up to four streams for monitoring previously recorded tracks - plus a click. Twelve lauded XMAX mic preamps provide all the gain you need to capture even the most subtle details without adding any extra noise. The analog mixer front-end makes connecting your gear to your computer intuitive, and creating monitor mixes is quick and easy.

The channel that does it all..even Bluetooth connectivity!
The unique Super Channel can handle four stereo sources at once and makes it easy to integrate consumer devices into your studio workflow. Connect a turntable to the RCA inputs, use the 1/8-inch stereo input to plug-in your smartphone, or forget the cable and connect it via Bluetooth wireless technology.

  • Specifications:

    • Mic Preamp
    • Type: XLR Female, Class A XMAX
    • Max Input level (unity gain): +9 dBu ±1.0 dB
    • Gain Control Range: 43 dB (+12 to +55 dB)
    • Freq. Resp. to Analog Outputs: 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Freq. Resp. to USB (Direct): 20 Hz to 20 kHz, +0.5/- 1.5 dB
    • S/N Ratio to Outputs (+4 dBu): 94 dB
    • THD+N (min. gain, A-wtd): < 0.01%
    • Input Impedance: 1 kΩ
    • EIN (+55 dB gain, 150Ω input, 20 Hz-22 kHz, A-wtd): Mono Ch: < 128 dBu
    • Common Mode Rejection Ratio (1 kHz, +55 dB gain): 65 dB
    • Phantom Power: +48V, ±3V, Global
      Note: All Channel Inputs sum through mic preamp

      Instrument Inputs
    • Type: 1/4" TS Female, Unbal., Hi-Z
    • Max Input Level (min. gain, 1 [email protected]% THD+N): +9 dBu ±1.0 dB
    • Gain Control Range: 43 dB, ±1 dB (+12 to +55 dB)
    • Freq. Resp. to Analog Outputs: 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Freq. Resp. to USB (Direct): 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Dynamic Range (min. gain, A-wtd): > 105 dB
    • Dynamic Range (mid. Gain, unwtd): > 108 dB
    • THD+N (1 kHz, -1 dBFS, A-wtd): < 0.01%
    • THD+N (1 kHz, -1 dBFS, unwtd): < 0.01%
    • Input Impedance: > 1 MΩ
      Note: All Channel Inputs sum through mic preamp

      Line Inputs
    • Type: 1/4" TRS Female, Balanced
    • Max Input Level (min. gain, 1 [email protected]% THD+N): +26 dBu ±1.0 dB
    • Gain Control Range: Mono Ch: 40 dB, ±1 dB (-5 to +35 dB), Stereo Ch: 0 dB or +10 dB (+10 dB Boost)
    • Freq. Resp. to Analog Outputs: 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Freq. Resp. to USB (Direct): 20 Hz to 20 kHz, +0.5/-1.5 dB
    • S/N Ratio to Analog Outputs (+4 dBu): 85 dB
    • THD+N (1 kHz, -1 dBFS, A-wtd): < 0.01%
    • Input Impedance (Balanced): 10 kΩ

      Main, Control Room, Monitor, and FX Outputs
    • Type (Main Outputs): XLR Male, Impedance Balanced
    • Type (Control Room, Monitor, FX Outputs): 1/4" TRS Female, Balanced
    • Rated Output Level (Main Outputs): +24 dBu, ±1.0 dB
    • Rated Outputs Level (Control Room, Monitor, FX Outputs): +18 dBu
    • Freq. Resp.: 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Dynamic Range (A-wtd): > 108 dB
    • THD+N (Bandwidth 20 Hz - 20 kHz, -1 dBFS, unwtd): < 0.01%
    • Output Impedance: 100 Ω

      Headphone Output
    • Type: 1/4" TRS Female, Stereo, Unbal.
    • Max Output Level: 150 mW/Ch @ 60 Ω
    • Freq. Resp.: 20 Hz to 20 kHz, +0.5/-1.5 dB
    • Dynamic Range (A-wtd): > 103 dB
    • THD+N (Bandwidth 20 Hz - 20 kHz, -1 dBFS, unwtd): < 0.01%

      System Crosstalk
    • Input to Output (Ref = +4dBu, 20 Hz to 20 kHz, unwtd): -90 dBu
    • Adjacent Ch (Ref = +4 dBu, 20 Hz to 20 kHz, unwtd): -85 dBu

      Signal Level LED
    • Signal: -30 dBFS (pre-EQ)
    • Clip: -3.0 dB before clip (pre- or post-EQ)

      Channel EQ
    • Low Cut: 100 Hz, -18 dB/Octave
    • High Shelving: ±15 dB @ 10 kHz
    • Mid Peaking (Mono Ch): ±15 dB @ 140 Hz to 3.5 kHz (variable)
    • Mid Peaking (Stereo Ch): ±15 dB @ 2.5 kHz
    • Mid-Band Q: Boost: 1.0, Cut: 2.5
    • Low Shelving: ±15 dB @ 100 Hz

      Digital Audio
    • Host Interface: USB 2.0
    • ADC Dynamic Range (Component): 114 dB
    • ADC Dynamic Range (Measured: A-wtd, 48 kHz): 105 dB
    • DAC Dynamic Range (Component): 114 dB
    • DAC Dynamic Range (Measured: A-wtd, 48 kHz): 105 dB
    • Signal-to-Noise (a-weighted): -96 dB
    • Bit Depth: 24-bit
    • Internally Supported Sample Rates: 44.1, 48, 88.2, 96 kHz
    • Jitter: < 80 ps RMS (20 Hz - 20 kHz)
    • Jitter Attenuation: > 60 dB (1 ns in => 1 ps out)

      SD Recorder
    • Supported Format: FAT16 formatted SD™ card, FAT32 formatted SDHC™ card
    • Media Storage: SD card: 2 GB; SDHC card: 32 GB
    • Recording Format: Stereo WAV
    • Playback Formats: Stereo WAV, MP3 (96-320 kbs, 32 / 44.1 / 48 kHz)
    • Sampling Rate (WAV): 44.1 kHz
    • Bit Depth: Recording: 24-bit, Playback: 16- or 24-bit

      Power/Environmental
    • Connector: IEC
    • Input Voltage Range: 90 to 240 VAC
    • Operating Temperature: 0° to 40° C / 32° to 104° F

      Physical
    • Height: 3.5"
    • Width (Chassis only): 18.9"
    • Depth: 15.6"
    • Weight: 14.1 lbs

  • Item Includes:

    • 1x PreSonus StudioLive AR16c
    • 1x 6-foot (1.8-meter), USB cable
    • 1x IEC power cord
    • 1x StudioLive ARc-series Quick Start Guide

  • Computer System Requirements

    :

    • Mac:
    • macOS® 10.11 or higher (64-bit only)
    • Intel® Core™ 2 Duo processor (Intel Core i3 or faster recommended)

      Windows:
    • Windows® 7 x64 SP1 + platform update, 8.1 x64, 10 x64
    • Intel Core 2 Duo (Intel Core i3 or faster)

      Mac and Windows Systems:
    • 4 GB RAM (8 GB or more recommended)
    • 30 GB hard-drive space (Studio One)
    • Internal or external 7200 RPM storage drive highly recommended
    • Monitor with 1366x768 resolution (high-dpi monitor recommended)

  • GTIN:

    0673454008573
