SmallHD VISION 24-Inch 4K HDR Production Monitor - 12G SDI & HDMI 2.0 - True 10-bit - 1000nits

ITEM #: SMHD-MONVISION24 MFG #: MON-VISION-24

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$14,999.00

After Savings:

$8,999.00

Availability: In Stock
iAvailability Description Popup
SmallHD Black Friday Instant Savings!Enjoy big savings on SmallHD items this holiday season! Get yours while supplies last!


MON-VISION-24 - Overview

The SmallHD Vision 24 allows you to see as your camera sees. Engineered to equal modern sensors' increased sensitivity to highlight and lowlight image retention. Powered by SmallHDR, a proprietary Full-Array Local Dimming (FALD) hardware that enables nuanced control of over 2176 individual LED zones, rendering hyper-sharp contrasts with deep blacks, crisp highlights, and a stunning 10-bit color depth. Ideal for use in any production environment where HDR monitoring is a necessity, Vision 24 provides the added security that every detail is captured.

  • Specifications:

    • Display
    • Panel Type: IPS LCD
    • Diagonal Size: 24.1
    • Resolution: 4096x2160
    • Brightness: 1000nits
    • Contrast: 1,000,000:1
    • Gamut: 115% DCI-P3
    • Color Depth: True 10-bit
    • Viewing Angle: 90°
    • Backlight Type: Full-Array Local Dimming
    • Backlight Zones: 2176
    • Display Size: 24"
    • Panel Resolution: 4096 x 2160
    • Color Bit Depth: True 10-bit
    • DCI-P3 Color: 115% DCI-P3

      Input Signal
    • 12G-SDI Input Types: 4x 12G-SDI
    • HDMI Input Types: 1x HDMI 2.0 (4K60)

      Output Signal
    • 12G-SDI Output Types: 4x 12G-SDI
    • HDMI Output Types: Coming Soon
    • Audio Output Types: 1x 3.5mm 3-pin Stereo Headphone Jack (coming soon)

      Power
    • Input: 1x 3-pin XLR (310W max, 12V-34V, 26A max)
    • Output:
      2x 2pin (12V/2A combined)
      1x USB (2.4A) (Front)
      1x USB (1.5A) (Front)
      1x USB-C (5V/1.5A)
    • Consumption: 225W (Monitor Only), 306W (w/ max access. power draw)
    • Battery Plate Included: No
    • Battery Types: 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)

      Data I/O Connector Type:
      1x SD Card Slot
      1x RJ45 Ethernet
      1x RJ45 GPI
    • Dimensions (HxWxD): 15.8" x 23.4" x 2.8" (w/o feet & handle), 16.9" x 23.7" x 4.7" (w/ feet & handle)
    • Weight: 19.7lbs (8.9kg)

  • Item Includes:

    • 1x Vision 24 4K HDR Production Monitor
    • 1x 3ft HDMI cable
    • 1x 8GB SC Card
    • 1x Vision 24 Basic Acrylic Locking Screen Protector
    • 1x Premium Monitor Handle for 4K Monitors
    • 1x 3-pin XLR Power Supply
    • 1x Cleaning cloth

  • GTIN:

    0811786032181
