Speco N16NU12TB 16 Channel Network Video Recorder/Server with POE - H.265 - 4K- 12TB

ITEM #: SPC-N16NU12TB MFG #: N16NU12TB

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$2,409.95

Our Price:

$2,189.60

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


N16NU12TB - Overview

Stream and record up to 16 video channels of video with the N16NU12TB PoE+ NVR from Speco Technologies at resolutions up to 8MP. Featuring an integrated PoE+ switch, this NVR enables you to power up to 16 IP cameras directly via network connection without the need for an external power source or extra cables. The recorder comes with 12TB of HDD storage preinstalled and supports up to 40TB.

The N16NU's connectivity interface has three USB ports and one RS-485 serial port, as well audio ports for two-way communication and HDMI, VGA, and CVBS video outputs. H.265 and H.264 compression help keep file sizes manageable while maintaining recording and playback quality. An IR remote control and mouse are included.

  • Features:

    • Record from and Manage up to 16 Cameras
    • Up to 8MP Recording Resolution
    • 12TB HDD Preinstalled
    • eSATA Port for Additional Storage

  • Specifications:

    • Video Input
    • Input Channels: 16
    • Maximum Resolution: UHD 4K (3840 x 2160)
    • Codec Support: H.265/H.264 Auto Detection

      Video Output
    • Main Monitor: 1 x HDMI, up to 3840 x 2160 Resolution, 1 x VGA, up to 1920 x 1080 Resolution
    • Sub Monitor: CVBS or Spot, Selectable

      Audio
    • Input/Output: 16/1
    • Audio Codec: G.711
    • 2-Way Audio: Local Audio to/from Network Client, Local Audio to/from IP Camera

      Alarm
    • Input/Output: 4/1

      Serial Interface
    • RS-485: 1

      Recording
    • Compression: H.265 and H.264, Auto Detection
    • Maximum Bit Rate: 8 Mb/s per Channel at 3840 x 2160
    • Maximum Frame Rate: 30 fps per Channel at Any Supported Resolution
    • Recording Modes: Continuous, Motion, Sensor, Schedule, Manual
    • Pre-Recording: Up to 20 Seconds
    • Post Recording: Up to 60 Seconds

      Playback
    • Search Modes: Quick, Date/Time, Archive, Log
    • Multi-Decoding: 1, 4, 9, 16
    • Playback Speed: x0.25, x0.5, x2, x4, x8, x16, x32, and x64

      Backup
    • Media: USB Flash Drive, External HDD, and Network
    • Format: BMP, AVI, Executable File (Player + Data), NSF (Proprietary Format)
    • Huge Backup: Up to 24 Hours

      Storage
    • Interface: 4 x SATA Ports
    • Capacity: Up to 10 TB per HDD (40 TB Total Max.), 12 TB Preinstalled
    • RAID: RAID 1, 5, 10
    • Capacity: Up to 16 TB
    • eSATA: 1
    • Extension: External DAS (Up to 40 TB, RAID)
    • USB Ports: Front: 2, Rear: 1
