PEX300WN2X2 - Overview

The StarTech PEX300WN2X2 PCI Express Wireless N Card (PCIe x1) adds high speed wireless network connectivity to almost any PCI Express-enabled desktop/workstation PC. Using a 2T2R (2 Transmitter/2 Receiver) design over the 2.4GHz frequency, this PCIe wireless card provides up to 300Mbps of data bandwidth over an 802.11n network, while improving signal reception and range.

Backward compatible with 802.11b/g networks (11/54Mbps), this WiFi N adapter offers a versatile wireless networking solution with support for standard and advanced security options such as WEP, WPA and WPA2, along with wireless Quality of Service (QoS) support and quick and easy setup through WPS.

This easy-to-install PCI Express 2.0 card is backed by StarTech's 2-year warranty and free lifetime technical support, making for an excellent wireless upgrade or first-time setup option.

Applications
Add wireless-N networking capabilities to a PCI Express-enabled desktop PCConnect a remote workstation PC to a wireless-N network, in environments where running network cables is not feasible

  • Features:

    • 2 Transmitter/2 Receiver (2x2:2) antenna configuration
    • Compliant with IEEE 802.11n standard, with support for up to 300Mbps of wireless data bandwidth
    • Backward compatible with IEEE 802.11b/g standards for up to 11/54Mbps connections respectively with Wireless-B and Wireless-G networks

  • Specifications:

    • Hardware
    • Antenna Configuration: 2x2:2 (TxR:S)
    • Bus Type: PCI Express
    • Card Type: Standard Profile (LP bracket incl.)
    • Chipset ID: Ralink - RT5392
    • Industry Standards: IEEE 802.11b, IEEE 802.11g, IEEE802.11n
    • Interface: Wireless Ethernet

      Performance
    • Bandwidth: 20/40 MHz
    • Frequency Range: 2.4 GHz ~ 2.484 GHz
    • Full Duplex Support: Yes
    • Maximum Data Transfer Rate: 802.11n: 300 Mbps
    • Modulation: OFDM/DSSS/DBPSK/DQPSK/CCK
    • Security Features: TKIP/AES
    • WEP Data Encryption
    • WPA and WPA2-PSK Data Encryption
    • WPA and WPA2 Enterprise Data Encryption
    • Supported Protocols: CSMA/CA

      Connector(S)
    • Connector Type(s): 2 - RP-SMA (Coax, Reverse Polarity SubMiniature A) Female

      Software
    • OS Compatibility: Windows® XP, Vista, 7, 8, 8.1, 10
    • Windows Server® 2003, 2008 R2
    • Linux 2.6.32 to 4.11.x LTS Versions only

      Indicators
    • LED Indicators: 1 - Link/Activity (green)

      Environmental
    • Humidity: 5 to 95% RH
    • Operating Temperature: -10° to 70°C (14° to 158°F)
    • Storage Temperature: -20° to 70°C (-4° to 158°F)

      Physical Characteristics
    • Height: 0.7" (1.8cm)
    • Length: 3" (75mm)
    • Width: 1.9" (49mm)
    • Weight: 1.3oz (38g)

      Packaging Information
    • Height: 1.4" (35mm)
    • Length: 6.5" (16.5cm)
    • Quantity: 1
    • Width: 5.5" (14cm)
    • Weight: 5.6oz (158g)

  • Item Includes:

    • 1x PCI Express Wireless Networking Card
    • 2x Antenna
    • 1x Low Profile Bracket
    • 1x Driver CD
    • 1x Instruction Manual

  • Warranty:

    • 2 Years

  • GTIN:

    0065030844482
