Turtle TAV-D2USB Dante Dual Channel USB-C I/O Adapter - TAA Compliant

ITEM #: TAV-D2USB MFG #: TAVD2USB

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$149.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


TAVD2USB - Overview

Experience flawless bi-directional conversion between two-channel USB audio and Dante 2CH digital audio with the Turtle AV Dante Pro Dual Channel USB-C I/O Adapter. This versatile adapter is USB audio device class 1.0/2.0 compatible, supporting USB output up to 24bit/192KHz and input up to 24bit/96KHz. With Dante audio sampling rates of 24bit at 44.1, 48, 88.2, and 96KHz, it delivers exceptional audio quality. The configurable Dante audio delay (1, 2, or 5 milliseconds) ensures precision in any setup. Power by PoE or USB-C, for maximum powering flexibility.

Dante Ultimo
In networked audio, precision is essential, and Dante by Audinate delivers with unmatched synchronization and ultra-low latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by the genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless, professional-grade sound for all installations, from live performances to intricate broadcast environments.

100% Dante Software Compatible
Turtle AV Dante Adapters are fully compatible with Dante Controller, Dante Domain Manager, and all Dante software applications.

Easy Control
Take command with Dante Controller. Our adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.

Audio Conversion
This adapter can be configured as either a two-channel USB to crystal-clear Dante digital audio converter, or a Dante digital audio to USB converter. It offers a versatile Dante audio sampling rate of 44.1, 48, 88.2, and 96KHz at 24-bit, ensuring high-quality sound. The configurable Dante audio delay can be set to 1, 2, or 5 milliseconds.

Sustainable, Earth-Friendly Design
Crafted with a commitment to sustainability, this adapter is made from 90% recycled plastic, including 5% Ocean Bound Plastic. The materials have been carefully selected to ensure there is no compromise to the ruggedness or durability. The packaging also contains no plastics or petrochemicals, and the box is made from 100% recycled cardboard and printed with soy-based ink. Turtle AV encourages you to just throw the packaging into the recycling to close the circle.

AES67 Lives Here Too
Dante Adapters support AES67 and Dante. Toggle between Dante and AES67 within Dante Controller.

  • Features:

    • Bi-directional conversion for two-channel USB audio and Dante 2CH digital audio
    • USB: Class Compliant USB 2.0 device
    • USB audio output up to 24bit/192KHz
    • USB audio input up to 24bit/96KHz
    • Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
    • Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
    • Analog audio input with support for 5-level gain adjustment
    • PoE and USB-C power options
    • TAA compliant
    • Made from 90% recycled plastic, including 5% Ocean Bound Plastic

  • Specifications:

      Technical
    • Input/Output: Interconverts between two-channel USB audio and Dante 2CH digital audio
    • USB Audio Class: 1.0/2.0-compatible
    • USB Audio Output: Up to 192KHz@24bit
    • USB Audio Input: up to 96KHz@24bit
    • Control: Dante Controller
    • Network Bandwidth: 100M
    • Audio Latency: Configurable Dante device latency (Supports 1, 2 or 5ms configurable using Dante Controller)
    • Audio Formats:
      - USB IN [Digital audio input, PCM 2CH 44.1K- 96KHz 16/24bit]
      - USB AUDIO OUT [Digital audio output, PCM 2CH 44.1K-192KHz 16/24bit]
      - DANTE IN/OUT [Digital audio output, PCM 2CH 44.1K-96KHz 16/24bit]
    • Audio Parameters:
      - Frequency Response: 20Hz to 20kHz (-/+0.5dB)
      - Dynamic Range: >100dB@0dBu, 1kHzA-weighted
      - Audio S/N Ratio: >100dB@0dBu, 1kHzA-weighted
      - Audio THD+N: < 0.01% at +4dBu, 1KHz
      - Audio Output Sync Delay: <10ms
    • ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

      Connections
    • Input/Output:
      - 1x USB-C [USB-C with USB 1.0/2.0, USB audio in/out, 12-pin female]
      - 1x POWER [USB-C power and firmware update port,12-pin female]
      - 1x DANTE [RJ45 LAN, PoE]

      Mechanical
    • Housing: Plastic Enclosure
    • Color: Black/Green
    • Dimensions: 4.52" x 1.57" x 1.1" (115mm x 40mm x 28mm)
    • Weight: 0.20lbs (94g)
    • Power Supply:
      - PoE: PoE IEEE802.3af Class 0
      - USB: 5V/500mA
    • Power Consumption: 2W (MAX)
    • Operating Temperature: 32°F - 104°F (-20°C - 60°C)
    • Relative Humidity: 20% - 90% RH (no condensing)

  • Item Includes:

    • 1x Turtle TAV-D2USB-PRO Dante Pro Dual Channel USB-C I/O Adapter

  • Warranty:

    • 3 Year Limited Warranty
