Thor Fiber H-8x8HDMI-SW 8 HDMI Input/Output Matrix Switcher - Supports up to 1080p 60Hz

ITEM #: THR-H-8X8HDMI-SW MFG #: H-8X8HDMI-SW

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

Our Price:

$995.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


H-8X8HDMI-SW - Overview

The Thor Fiber H-8x8HDMI-SW is an easy to use video accessory that allows any HDMI source to go into a matrix with outputs going out to 8 different HDMI enabled screens. These units are HDMI and HDCP compliant meaning they can be used with any HDMI source including a set top box, gaming system, PC, Blu Ray etc.

Using various controls the HDMI Matrix switch is a breeze to setup; comes stock with RS232 control, an IR remote, web GUI with login, smart EDID management, and front panel buttons to quickly access the HDMI input to the HDMI output of your choice. Every input and output is capable of resolutions up to 1080p60hz and the unit itself can be installed in a 19 inch rackmount shelf or simply placed on a table top. Quick and efficient, this matrix switcher will allow you create a multi viewing HDMI environment for any scenario such as bars, restaurants, conferences, security, government, hospitals, education, sports, and courts

  • Features:

    • Supports video resolutions up to 1080p@60Hz.
    • Compliant with the HDMI 1080P60 and HDCP 1.4 specifications
    • Smart EDID management to match the connected displays
    • Front panel buttons, internet web GUI, and RS232 control
    • Includes IR remote control
    • Rackmount or Table Top installation

  • Specifications:

    • Input: 8x HDMI
    • Input Connector: 8x female type A HDMI
    • Output: 8x HDMI
    • Output Connector: 8x female type A HDMI
    • Control: Firmware, TCP/IP, RS232
    • Control Connectors:
      - 1x Micro-USB
      - 1x RJ45
      - 1x Female DB9
    • Video Resolution: Up to 1080p@60Hz 4:4:4 8bit
    • HDMI Version: 1.3a
    • HDCP Version: 1.4
    • HDMI Input Cable: 15 meters
    • HDMI Output Cable: 15 meters
    • Bandwidth: 5.6Gbps
    • Control Options:
      - Front Panel
      - IR Remote
      - Web GUI
      - RS-232
    • Power Supply:
      - Input: 100V - 240V AC
      - Output: 24V DC 1.25A
    • Power Consumption: 13.5W (Max)
    • Operation Temperature: 23°F - 131°F (-5°C - 55°C)
    • Storage Temperature: -13°F - 158°F (-25°C - 70°C)
    • Relative Humidity: 10% - 90%
    • Dimension (WxHxD): 16.14" x 1.1 " x 6.3"
    • Net Weight: 3.6lbs

  • Item Includes:

    • 1x H-8X8HDMI-SW Switch
    • 1x Power Cable
    • 1x Power Adapter
    • 1x RS232 Cable
    • 1x Remote Control
    • 1x Data CD
    • 1x Instruction Manual
