Yamaha RMIO64-D Dante/MADI Conversion I/O Rack

ITEM #: YMH-RMIO64-D MFG #: RMIO64-D

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Yamaha Corporation
Free Shipping with $49 Minimum Order

List Price:

$4,199.00

Our Price:

$3,679.00

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

RMIO64-D - Overview

The Yamaha RMio64-D is a digital interface that lets you transfer up to 64 digital inputs and 64 digital outputs between a Dante network and a MADI-compatible device. By connecting both Dante and MADI, this product can be used for a wide variety of applications such as broadcasting, live recording, and post production. In addition, full control of this units' settings has been achieved through tight integration with Yamaha's Dante compatible devices.

  • Features:

    • Supports redundancy for both Dante and MADI, and provides a high level of reliability
    • Sampling rate converter (SCR) in MADI inputs and outputs
    • Signals can be looped back from MADI optical to coaxial, or from coaxial to optical (MADI split)
    • Enhanced linkage functionality with Steinberg Nuendo, such as direct monitoring and high-precision clock sync with Nuendo SyncStation


  • Specifications:

    • Sampling Frequnecy Rate (Internal): 44.1kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm) / 48kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm) / 88.2kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm) / 96kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm) / 176.4kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm) / 192kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±50ppm)
    • Sampling Frequnecy Rate (External): 44.1kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 48kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 88.2kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 96kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 176.4kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm) / 192kHz: +4.1667%, +0.1%, -0.1%, -4.0% (±200ppm)
    • MADI Channels & Formats: fs=44.1kHz/48kHz:MADI Single fs 44.1/48k frame, 56/64 channels / fs=88.2kHz/96kHz:MADI Double fs 44.1/48k frame, 28/32 channels / MADI Double fs 88.2/96k frame, 28/32 channels / fs=176.4kHz/192kHz:MADI Quad fs 44.1/48k frame, 14/16 channels
    • SRC: SRC Lock Range:38.59kHz - 216kHz / Sample Rate Ratio Limit:6:1
    • Dimensions (WxHxD): 18.90 x 1.73 x 14.72"
    • Net Weight: 10.4 lbs.
    • Power Requirements (wattage): 25W
    • Power Requirements (volts and hertz): 120V 60Hz
    • Temperature Range: Operating: 32 to 104°F Storage: -4 to 140°F


  • Item Includes:

    • Owner's Manual
    • AC Power Cord


  • GTIN:

    0086792995557
