Apantac DA-HDTV-SDI-UHD HDMI 2.0 to SDI Converter with Looping Input and Fiber Output

ITEM #: APA-DAHDTVSDIUHD MFG #: DA-HDTV-SDI-UHD

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Apantac
Free Shipping with $49 Minimum Order

Our Price:

$1,500.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

DA-HDTV-SDI-UHD - Overview

Apantac DA-HDTV-SDI-UHD is a HDMI UHD to 12G SDI converter. It supports HDMI 2.0, 1.4 (including 4K30Hz and 4K60 4:4:4) input and converts to SDI up to 12G SDI output with optional SDI fiber output.

  • Features:

    • Supports HDMI 2.0 video input and loop out
    • Supports up to UHD@60Hz (4:4:4)
    • Outputs up to 12G SDI
    • Optional 12G SDI fiber output via SFP
    • Status LEDs
    • Stereo AES and AA audio monitoring outputs
    • 12V DC with power loop to power other devices


  • Specifications:

    • HDMI Inputs: 1 x HDMI up to UHD
    • Analog Audio Output: Selectable stereo pair
    • HDMI Outputs: 1 x HDMI up to UHD
    • AES Audio Output: Selectable stereo pair
    • SDI Output: Up to 12G SDI
    • Switch: Between fiber and BNC
    • Optional Fiber Output: 1 x SFP
    • Power: 12V DC with looping


  • Item Includes:

    • 1x DA-HDTV-SDI-UHD
    • 1x Locking Power Supply (12V/3.34A)
    • 1x Magnetic Mounting Plate
