APC SRT6KRMXLT Smart-UPS SRT 6000VA RM 208V

ITEM #: APC-SRT6KRMXLT MFG #: SRT6KRMXLT

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

List Price:

$10,325.00

Our Price:

$7,475.00

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Shipped truck freight.
  • Special Order Item: non-cancelable, non-returnable, non-refundable.


SRT6KRMXLT - Overview

APC Smart-UPS SRT 6000VA RM 208V

High density, double-conversion on-line power protection with scalable runtime

Includes : CD with software , Documentation CD , Installation guide , Rack Mounting brackets , Rack mounting hardware , Rack Mounting support rails , Temperature Probe , USB cable , Warranty card , Web/SNMP Management Card

10/100 BaseT Connection: Connect the device to a network using a 10 or 100 BaseT connection
Battery failure notification: Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Green mode: Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Hard Wire Input: UPS requires a hard wire input in order to deliver maximum output wattage to protected equipment
LCD graphics display: Text and mimic diagrams that display modes of operation, system parameters and alarms.
Rack/Tower convertible: Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

  • Specifications:

    • Output
    • Output power capacity: 6.0 KWatts / 6.0 kVA
    • Max Configurable Power (Watts): 6.0 KWatts / 6.0 kVA
    • Nominal Output Voltage: 208V
    • Output Voltage Distortion: Less than 2%
    • Output Frequency (sync to mains): 50/60Hz +/- 3 Hz
    • Other Output Voltages: 240
    • Load Crest Factor: 3 : 1
    • Topology: Double Conversion Online
    • Waveform type: Sine wave
    • Output Connections:
    • (1) Hard Wire 3-wire (2PH + G) (Battery Backup)
    • (2) NEMA L6-20R (Battery Backup)
    • (3) NEMA L6-30R (Battery Backup)
    • Bypass: Internal Bypass (Automatic and Manual)

    • Input
    • Nominal Input Voltage: 208V
    • Input frequency: 40 - 70 Hz (auto sensing)
    • Input Connections: Hard Wire 3-wire (2PH + G)
    • Input voltage range for main operations: 160 - 275V
    • Input voltage adjustable range for mains operation: 100 - 275 (half load)V
    • Other Input Voltages: 240

    • Batteries & Runtime
    • Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
    • Typical recharge time: 1.5hour(s)
    • Replacement Battery: APCRBC140
    • RBC Quantity: 1
    • Extendable Run Time: 1
    • Battery Volt-Amp-Hour Capacity: 875

    • Communications & Management
    • Interface Port(s): RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB
    • Control panel: Multi-function LCD status and control console
    • Audible Alarm: Audible and visible alarms prioritized by severity
    • Emergency Power Off (EPO): Yes
    • Available SmartSlot Interface Quantity: 1

    • Surge Protection and Filtering
    • Surge energy rating: 480Joules

    • Physical
    • Maximum Height: 6.85inches ( 174mm , 17.4cm )
    • Maximum Width: 17.0inches ( 432mm , 43.2cm )
    • Maximum Depth: 28.32inches ( 719mm , 71.9cm )
    • Rack Height: 4U
    • Net Weight: 135.0lbs. ( 61.23kg )
    • Shipping weight: 150.0lbs. ( 68.04kg )
    • Shipping Height: 14.57inches ( 370mm , 37.0cm )
    • Shipping Width: 24.02inches ( 610mm , 61.0cm )
    • Shipping Depth: 37.8inches ( 960mm , 96.0cm )
    • Color: Black

    • Environmental
    • Operating Environment: 32 - 104 °F ( 0 - 40 °C )
    • Operating Relative Humidity: 0 - 95% no %
    • Operating Elevation: 0-10000ft ( 0-3000meters )
    • Storage Temperature: -15 - 45 °C
    • Storage Relative Humidity: 0 - 95% no %
    • Storage Elevation: 0-50000ft ( 0-15000meters )
    • Audible noise at 1 meter from surface of unit: 55.0dBA
    • Online thermal dissipation: 1402.0BTU/hr
    • Protection Class: IP 20

    • Conformance
    • Approvals: CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, NOM, UL 1778
    • Standard warranty: 3 years repair or replace (excluding battery) and 2 years for battery

    • Sustainable Offer Status
    • RoHS: Compliant
    • REACH: Contains No SVHCs
    • Battery Directive: Compliant

  • GTIN:

    0731304308522
