EAW Radius RSX12M 2-Way Self-Powered Stage Monitor - 500W

ITEM #: EAW-RSX12M MFG #: RSX12M

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Eastern Acoustic Works
Free Shipping with $49 Minimum Order

Our Price:

$2,175.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

RSX12M - Overview

Designed to streamline setup and deliver maximum results in minimum time, RADIUS couples unique and intelligent features with EAW's signature acoustical design to deliver solutions for rental firms and system integrators. The RSX12M features onboard bi-amplified electronics (500W peak) featuring signature EAW DSP including Focusing and DynO for pristine impulse response. MK inspired constant directivity horn offers 105°x105° coverage. EAWmosaic app provides total system optimization from anywhere in the venue, plus intuitive room design and prediction in a single, comprehensive application. With the proven sonic performance of EAW's acoustic design and DSP mastery plus full Dante integration across the line, RADIUS delivers an intelligent and flexible system to fit any budget.

Perfect Applications Include:
House of Worship
Theatres, Auditorium and Performing Arts Centers
Live Music Clubs
Corporate AV Houses
Live Production/Regional Rental Houses
Dry Hire

  • Features:

    • Extremely approachable EAWmosaic™ iOS app delivers system prediction, control and monitoring from any location in the venue.
    • Proven EAW acoustical design and DSP including Focusing™ and DynO™ provides a pristine impulse response at all output levels.
    • Four pre-defined voicings provide a variety of tonal starting points while also offering maximum feedback stability.
    • Integrated Dante™ networking (with loop-thru) on all models including Analog redundancy capability.
    • Low latency of just 2.6 ms provides excellent transparency for vocal monitoring applications


  • Specifications:

    • CONFIGURATION
    • Subsystem:
    • Transducer: 1 x 12 in cone, 2.5 in voice coil; HF - 1 x 1 in exit, 1.77 in voice coil compression driver
    • Loading: LF - Vented; HF - Horn-loaded
    • Operating Mode:
    • Amplifier Channels: Bi-amp (LF/HF)
    • Signal Processing: DSP w/EAW Focusing™ and DynO™

      PERFORMANCE
    • Operating Range: 55 Hz to 18 kHz
    • Nominal Beamwidth: Horizontal 105°; Vertical 105°
    • Calculated Axial Output Limit (whole space SPL): Average: 122 dB (LF/HF); Peak: 128 dB (LF/HF)
    • Input Type: Electronically balanced
    • Max Input Level: 21dBu
    • Impedance: 20 kOhm (balanced)
    • Input Wiring: XLRF, Pin 1 chassis, pin 2 +, pin 3 - Separate loop-thru XLRM (for analog signal only)
    • Input Selection: Analog, Dante
    • Amplifiers & Processing (LF/HF) Type: Modified Class D (LF/HF)
    • Maximum Output: 500W (LF/HF)
    • Driver Protection: Integral DSP limiting (LF/HF)
    • AC Mains (nominal) Connector: Neutrik PowerCon
    • Input: 100 V to 240 V
    • Frequency: 50 Hz to 60 Hz
    • Power Consumption: Idle - 22 W
    • Peak Draw: 175 W
    • Controls/Communication Connections: 2x Neutrik etherCON, RJ-45
    • Protocols: Ethernet/Dante
    • Software: EAWmosaic™ (available on the App Store)
    • Indicators: LCD Screen on amplifier panel for UI, Logo LED (User-definable behavior)
    • User Controls: Push-button Rotary Encoder

      PHYSICAL
    • Dimensions (inches/millimeters):
    • Height: 13.1/333
    • Width: 19.7/501
    • Depth: 19.2/489
    • Weight (pounds/kilograms): 36/16.3
