ETS PA875 Balanced Analog Audio - 6.00 Pigtail MXLR to RJ45 Pins 5 and 4

ITEM #: ETS-PA875 MFG #: PA875

Primary Image

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ETS-PA875

PA875 - Overview

The ETS PA875 Series of Balanced Analog Audio Adapters is ideal for use in applications requiring audio signals to be sent over distances greater than 4 meters. Signals may be sent in either direction. By balancing the audio signal as well as isolating it, signals can be easily sent over 100 meters distance.

  • Features:

    • Full audio bandwidth
    • Minimizes spurious signal ingress
    • Eliminates ground loops
    • Compact plastic case
    • Made in USA
    • 100% tested


  • Specifications:

    • Bandwidth: 10 Hz to 20 kHz
    • Connectors: Screw Terminals to RJ45
    • Impedance: 600:600
    • Isolation: 500V
    • Signal Level: 1.0 V
    • Distance: 1000 FT
    • Dimensions: 66 x 66 x 28mm
    • Weight: 0.08 Kg
