ETS PA876 Balanced Analog Audio Adapter with 6 Inch Pigtail FXLR to RJ45 Pins 5 and 4

ITEM #: ETS-PA876 MFG #: PA876

Primary Image

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ETS-PA876

PA876 - Overview

The ETS PA876 is a balanced analog audio Adapter with a 6 inch pigtail female XLR to RJ45 pins 5 and 4. The ETS PA870 Series of Balanced Analog Audio Adapters is ideal for use in applications that require audio signals to be sent over distances greater than 4 meters. Signals may be sent in either direction. By balancing the audio signal as well as isolating it, signals can be easily sent over 100 meters distance. Perfect for Churches, Theaters, Classrooms, Auditoriums or anywhere you need to send analog audio.

  • Features:

    • Full audio bandwidth
    • Minimizes spurious signal ingress
    • Eliminates ground loops
    • Compact plastic case
    • Made in USA.
    • 100% tested

  • Specifications:

    • Bandwidth: 10 Hz to 20 kHz
    • Connectors: Screw Terminals to RJ45
    • Impedance: 600:600
    • Isolation: 500V
    • Signal Level: 1.0 V
    • Distance: 1000 FT
    • Dimensions: 66 x 66 x 28mm
    • Weight: 0.08 Kg
