StarTech SV565UTPDUV USB DVI over Cat 5e / Cat 6 KVM Console Extender w/ 1920x1200 Uncompressed Video - 330ft (100m)

ITEM #: ST-SV565UTPDUV MFG #: SV565UTPDUV

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the ST-SV565UTPDUV

SV565UTPDUV - Overview

The SV565UTPDUV USB DVI KVM Extender lets you control a PC from up to 330ft (100m) away over a single Cat 5e or Cat 6 cable connection, with uncompressed 1920x1200 DVI video and access to up to 3 connected USB devices.

A flexible solution for powering large high-definition displays remotely, this DVI USB extender supports uncompressed 1920x1200 video resolution at maximum distance, with 24-bit color depth.

This versatile KVM console extender can be connected to a single system, or cascaded to an existing KVM switch for remote operation of multiple systems, and features 3 USB 2.0 ports on the remote end, allowing you to connect a keyboard, mouse, printer or other peripherals. Since the extender uses Cat 5e (or better) network cable, you have the option to use existing infrastructure wiring, which helps avoid the hassle and expense of running bulky video cables.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

  • Features:

    • Uncompressed 1920x1200 HD video extension
    • Extend up to 330 ft (100m) over a single Cat5e / Cat6 cable
    • OS independent - no software or drivers required
    • 3 USB 2.0 ports with transfer rates up to 30Mbps
    • Supports connection to a single computer or cascading to an existing KVM switch
    • Supports most combo keyboard and mouse sets (including Wireless)


  • Specifications:

    • Hardware
    • Audio No
    • Daisy-Chain Yes
    • KVM Ports 1
    • Multi-Monitor No
    • PC Interface USB
    • PC Video Type DVI
    • Rack-Mountable No

    • Performance
    • Color Depth 24-bit, 16.7M colors (Truecolor)
    • IP Control No
    • Max Transfer Distance 100 m (328 ft)
    • Maximum Data Transfer Rate 30 Mbps (USB)
    • Maximum Digital Resolutions Full Uncompressed 1920x1200

    • Connector(s)
    • Console Interface(s) 1 - DVI-D (25 pin) Female
    • 1 - RJ-45 Female
    • 3 - USB A (4 pin) Female
    • Host Connectors 1 - DVI-D (25 pin) Female
    • 1 - RJ-45 Female
    • 1 - USB B (4 pin) Female

    • Software
    • OS Compatibility OS independent; No software or drivers required
    • Special Notes / Requirements
    • Note Product measurements indicate a single unit only (either Host or Remote)

    • Indicators
    • LED Indicators 1 - Power
    • 1 - Link
    • 1 - USB
    • 1 - Video

    • Power
    • Center Tip Polarity Positive
    • Input Current 0.6 A
    • Input Voltage 100 ~ 240 AC
    • Output Current 3 A
    • Output Voltage 5 DC
    • Plug Type C
    • Power Source 2 AC Adapters Included


  • Item Includes:

    • 1 - Local Extender Unit
    • 1 - Remote Extender Unit
    • 2 - Mounting Brackets
    • 1 - DVI Cable
    • 1 - USB Cable
    • 2 - Universal Power Adapters
    • 6 - Power Cords (2 sets, NA/EU/UK)
    • 1 - Quick Start Guide


  • Warranty:

    • 2 Years


  • GTIN:

    0065030853347
