JBL CST2120 Rack-Mountable Transformer Module for CSA-2120 Amplifier to Drive 70V and 100V Speaker Systems

ITEM #: JBL-CST2120 MFG #: CST2120

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
JBL Professional
Free Shipping with $49 Minimum Order

List Price:

$187.30

Our Price:

$173.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

CST2120 - Overview

The rack-mountable JBL Commercial CST-2120 transformer module provides impedance and voltage matching for the CSA-2120 amplifier to drive 70V and 100V distributed speaker systems.

  • Features:

    • Providing two channels for constant voltage operation
    • 70V/100V Outputs
    • Rack-mountable with CSA2120
    • Detachable block input and output connectors


  • Specifications:

    • Max Input Power: 120W/Ch
    • Max Input Voltage: 32Vrms
    • Insertion Loss: Less than 1dB
    • Frequency Response: +/-1 dB @ 70Hz - 15kHz
    • Dimensions: 8.2 inch x 1.7 inch x 7 inch (209 mm x 44 mm x 178 mm)


  • GTIN:

    0871015006147
