Newtek NDIHX-PTZ1 NDI SDI and HDMI PTZ Camera

ITEM #: TRI-NDIHX-PTZ1 MFG #: FG-001777-R001

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the TRI-NDIHX-PTZ1

FG-001777-R001 - Overview

The NewTek NDIHX PTZ1 NDI PTZ Camera with Bulit-in NDI - the fastest, easiest way to get IP video into your production with Video, Audio, Control, Tally and Power all on one ethernet cable.

Imagine the possibilities of a camera that can serve as a live video input for any NDI-compatible hardware or software-from anywhere on your network. Introducing NDIHX-PTZ1, the faster, easier, and better way to capture live video.

Unlike typical cameras, PTZ1 leverages the ground-breaking benefits of the NDI-based IP workflow supported by leading video software and hardware developers around the globe.

  • Features:

    • Native support for HD video formats up to 1080p 60
    • Integrated and automatic tally support via NDI
    • Motor-driven pan-tilt-zoom operation with preset positions
    • Remote control & monitoring via Web-based user interface
    • Remote control over IP via NewTek Studio Monitor
    • Remote capture & recording via NewTek Studio Monitor
    • Power over Ethernet via POE+ (802.3at) or included DC 12V 1A external supply - Mounting bracket included
    • Compatible with professional and prosumer production solutions including NewTek live production systems and third-party video switchers, as well as software-based video tools like Livestream Studio, OBS, Streamstar SW, Telestream Gameshow and Wirecast, VidBlaster, vMix, XSplit, and all other NDI-compatible products (NDI version 2.0 or higher)
    • Compatible with popular desktop video applications via NDI HX driver, including Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, and more


  • Specifications:

    • Video Output: Video output via NDI HX, 3G-SDI, and/or HDMI
    • Video Formats: 1080p: 60, 59.94, 50, 30, 29.97; 1080i: 59.94, 50; 720p: 60, 59.94, 50
    • Lens Zoom: 20x Optical / 12x Digital
    • Lens Focal Length: 4.7mm to 94mm
    • Lens Aperture: F1.6 to F3.5
    • Shutter Speed: 1/1 to 1/10,000 sec
    • Rotation Speed: 300°/sec maximum
    • Panning Angle: -170° to +170°
    • Tilting Angle: -30° to +90°
    • Horizontal Viewing Angle: 63°
    • Flip: Integrated image flip and mirror function for flexible installation
    • Audio Input: 3.5mm stereo audio input (line)
    • Tally: Tally support via NDI HX
    • Focus System: Auto, Manual
    • White Balance: Auto, Manual, Indoor, Outdoor, One-Push
    • Gain Control: Auto, Manual
    • Exposure Control: Auto, Manual
    • User Interface: Remote configuration, control, and monitoring via Web-based user interface or NewTek Studio Monitor application
    • Networking: 1 x RJ45 port for 10/100 M Ethernet networking
    • Power: Power over Ethernet via POE+ (802.3at) or included DC 12V 1A external supply
    • Dimensions: 6.9 x 7.2 x 7.2 in
    • Weight: 4.0 lbs
