Theatrixx XVVAUDIO2SDIT1 xVision Converter - Audio Embedder - HDMI1.2/3G-SDI + Audio to 3G-SDI - PowerCON True1 In/Thru

ITEM #: TT-XVVAUDIO2SDIT MFG #: XVVAUDIO2SDIT1

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

Our Price:

$705.00

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


XVVAUDIO2SDIT1 - Overview

Professional equipment in mission-critical applications is all about reliability and confidence. So we started with a clean sheet, and built what might soon become your most trustworthy piece of equipment. Introducing the world's first video converters truly designed for the road. Video converters nowadays are used everywhere on professional A/V events, presentations, live shows and tours and often have a critical role yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. We wanted to change that, so we designed the xVision Video Converters.

  • Features:

    • Integrated power supply with locking PowerCON True 1 Connector. Never rely on a cluster of wall-warts again.
    • Built-in convenience outlet to power nearby monitor, flat-screen, laptop, video projector or any device up to 10 amps. Power bar to connect both converter and device not required anymore.
    • Magnetic stacking system and non-skid rubber pad for table top application. Saves at least 10 gaffer tape rolls a year.
    • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adapter.
    • Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
    • Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
    • Clear and ample status LED indicators for quick troubleshooting.
    • Easy on-the-field identification with unique color and alphabetic coding system.
    • Locking HDMI port prevents accidental disconnection.
    • Professional balanced -4dB XLR analog audio inputs each with a 3-segment LED meter.
    • Combines analog audio with incoming HDMI or SDI into a reclocked SDI output - with automatic input detection.
    • Proudly designed and assembled in Canada.

  • Specifications:

    • Video Input: Auto switching between 1 x 3G/HD/SD SDI, BNC & 1 x HDMI 1.4 type A with locking system
    • Audio Input: 2 x Balanced + 4dB XLR (analog) each with a 3-segment LED meter.
    • Video Output; 1 x 3G/HD/SD SDI BNC..
    • 3G Format Support: 1080p50, 1080p59.94, 1080p60.
    • HD Format Support: 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30.
    • SD Format Support: 525/23.98 NTSC, 525/29.97 NTSC.625/25 PAL.
    • SDI Video Sampling: 4:2:2 and 4:4:4.
    • SDI Audio Sampling: Sample rate of 48 kHz and 24 bit.
    • SDI Color Space: YUV and RGB.
    • SDI Auto Switching: Automatically detects incoming signal format.
    • Embedding to: SDI Channels 1 & 2.
    • SMPTE Standards: 425M Level A & B, 424M Level A, 292M, 259M.
    • Height: 50 mm (1.97 in).
    • Depth: 180 mm (7.08 in).
    • Width: 107 mm (4.21 in).
    • Weight: 1 kg (2.2 lbs).
    • Relative Humidity: 0% to 90% non-condensing.
    • Operating Temperature: 0-40 °C.
    • Power Supply: Built-in power supply, PowerCON True1 input, PowerCON True1 output (loop-thru).
    • Power Consumption: 15W.
    • Voltage Range: 100-240V, 50-60Hz, (100-120V, 50-60Hz available with PowerCON/Edison Nema 5-15).
    • Courtesy Outlet: Max 10 A, same voltage as input.

  • Item Includes:

    • xVision Converter SDI Audio Embedder True1
    • Locking HDMI male to DVI male (1m)
    • AC Mains to PowerCON True1 cable
