EDA-2100 - Overview

The FOR-A EDA-2100 Provides distribution of up to eight outputs when one channel of input is used. The EDA-2100 supports 12G-SDI I/O and is a 1U model with redundant power supply. Using a 12G-SDI input, set a delay of up to 5 sec. Add an EDA-20EX option for delay up to 10 sec. Note: Available delay when four inputs are used is divided equally among channels (¬ the delay available for one channel).

  • Features:

    • Delay of up to 80 sec. available (optional)
    • Multi-format support
    • Use SNMP for trap output or to check or configure settings
    • Remote control via Telnet with dedicated remote unit, the EDA-20RU
    • Genlock using external reference signals is enabled


  • Specifications:

    • Video Formats
    • 3G-SDI: 1920 x 1080/59.94p, 1920 x 1080/50p
    • HD-SDI: 1920 x 1080/59.94p, 1920 x 1080/50i
    • SD-SDI: 720 x 483/59.94i, 720 x 576/50i

      Video Inputs
    • 3G-SDI: 1080/59.94p, 1080/50p, SMPTE ST 424 Compliant
    • HD-SDI: 1080/59.94i, 1080/50i, SMPTE ST 292-1 Compliant
    • SD-SDI: 720/59.94i, 720/50i, SMPTE ST 259 Compliant

      Video Outputs
    • 3G-SDI: 1080/59.94p, 1080/50p, SMPTE ST 424 Compliant
    • HD-SDI: 1080/59.94i, 1080/50i, SMPTE ST 292-1 Compliant
    • SD-SDI: 720/59.94i, 720/50i, SMPTE ST 259 Compliant
    • 75Ω BNC x 8 (4 Lines, up to 8 Distributed outputs when 1 line is used

      Delay(Max)
    • 3G-SDI: Approx. 20 sec. (40 sec)
    • HD-SDI: Approx. 40 sec. (80 sec)
    • SD-SDI: Approx. 120 sec. (240 sec)

      Delay Adjustment
    • Video: Effective video section
    • Audio: HANC Space including audio signals
    • Vanc: Vanc Space

      Reference Input
    • BB: NTSC: 0.429 Vp-p/PAL: 0.45 Vp-p
    • Tri-level Sync: 0.6 Vp-p, 75Ω, BNC x 1 with loop-through

      Phase Adjustment
    • H Phase: +/- 0.5 Line, 1 Sample Step
    • V Phase: +/- 0.5 Frame, 1 Line Step

      Lan
    • 100Base-TX, RJ-45 x 1 (remote control, SNMP v2c monitoring/control)

      Alarm
    • 15-pin D-sub (female), Fixed inch screw thread x 1 (Alarm output)

      Alarm Output
    • Power, FAN, Input signal fault detection, Genlock signal fault detection
    • Output from SNMP-trap, ALARM connector

      Temperature/Humidity
    • 5°C to 40°C/10% to 80% (no condensation)

      Power/Consumption
    • 100 V AC to 240 V AC +/- 10%, 50/60 HZ/50 W (at 100 V AC)

      Dimensions/Weight
    • 430(W) x 44(H) x 400(D), approx 6kg


  • Item Includes:

    • 1x AC Cord
    • 1x CD-ROM (Operation Manuals)
    • 1x Rack-Mount Brackets
