Dataprobe iBoot-PDU8A-C10 Switched PDU 8 Outlet IEC 10A

ITEM #: IBOOT-PDU8A-C10 MFG #: IBOOT-PDU8A-C10

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$580.00

Our Price:

$549.00

Availability: In Stock
iAvailability Description Popup


IBOOT-PDU8A-C10 - Overview

When you need to reduce costly site visits, ensure business continuity and increase network reliability, the Dataprobe IBOOT-PDU8A-C10 gives you peace of mind. iBoot-PDU, a web-accessible, managed PDU independently controlled outlets, enables multiple users to reboot remotely from anywhere, using any web browser, Telnet client or SNMP manager.

From servers and webcams to IP PBXes and surveillance systems, iBoot-PDU keeps your network up and running.

iBoot-PDU - Simple web browser interface
The web browser interface provides the easiest means of managing multiple outlets. One master unit can be connected to 15 expansion units, managing 128 outlets from a single web page interface.

The web page presents a clear status indication of each outlet, current draw across all inputs and the AutoPing monitoring, if implemented.

Each outlet can be individually selected, or multiple outlets can be simultaneously operated. User selectable cycle timer allows single command reboot. Delay timer limits inrush current by staggering power up when multiple devices are simultaneously controlled.

Cloud Manageable
iBoot Cloud Service (iBCS) allows customers with iBoot-PDU to access and control multiple units in multiple locations from a single portal with a single sign-on.

iBCS will not only make using iBoots easier, by consolidating all units into one sign-on and interface, it will also enhance the number of situations where iBoot can be deployed.

iBoot-PDU Web Browser Video
iBoot-PDU Web UI Video

iBoot-PDU - Sophisticated Automation
Monitor critical parameters and take corrective action immediately. Build complex notification and reporting for environmental, power and network faults. Set trigger points and create sequences of responses to keep your network up and running.

AutoPing
Temperature with accessory probe
Mains Current
Mains Voltage
Time of Day

  • Features:

    • 4 and 8 Outlet Managed PDU
    • NEMA and IEC Versions
    • Cloud Manageable
    • Environmental Monitoring
    • Wide Temperature Range

  • Specifications:

    • Mechanical
    • Height: 1U 1.75" (4.5cm)
    • Width: 11" (27.94cm)
    • Depth: 6" (15.25cm)
    • Weight: 4.5Lbs (2kg)

      Environmental
    • Operating Temperature: 32° to 149°F (0° to 65°C)
    • Storage Temperature: 14° to 185°F (-10° to 85°C)
    • Relative Humidity: 0 to 95% Non-Condensing
    • Altitude: 2000m Operating

      A/C Power Input
    • 100-240 VAC VAC
    • 10 AMP Models: IEC320 C14 Receptacle
    • 20 AMP Models: IEC320 C20 Receptacle

      Network
    • Single or Dual (S Models) 1G Ethernet
    • Web, Telnet, SNMP, SMTP Port Assignable for Web and Telnet
    • SSL Security on Web control

      USB Ports
    • 4x USB A ports for accessories, modem, temperature probe, etc.
    • 1x USB B port for serial port and external battery

      Switched Outlet
    • 4 or 8 NEMA 5-15 Recepticle
    • 12 Amps Max per Receptacle
    • -N15 Models:, 15 Amps Max Total per Linecord
    • -N20 Models , 20 Amps Max Total per Linecord

      Compliance - Safety
    • Complies with UL62638-1, 2nd Edition, 2014-12-01 (US),
    • IEC62638-1:2014 EN 62368-1:2014 + A11:2017
    • Complies with CAN/CSA C22.2 No. 62638-1-14, 2nd Edition, 2014-12-01 (Canada)

      Compliance - Emissions
    • ANSI C63.4:2014 & 47 CFR Part 15, Subpart B, Class B
    • ICES-003:2016 Issue 6, Class BFCC Part 15 Class B

      Compliance - Environmental
    • RoHS 3 Directive (EU) 2015/863Compliant
    • WEEE Compliant
    • Rated Pollution Degree 2 (PD 2) for use in business/laboratory environments with only Non-Conductive pollution present
