Osprey MVS-8 1RU 8 Channel 3G-SDI 19 Inch LCD Rackmount Multi Viewer with Audio Bars and Time Code Display

ITEM #: OSP-MVS-8 MFG #: 97-50002

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Osprey Video
Free Shipping with $49 Minimum Order

List Price:

$1,690.00

Our Price:

$1,597.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

97-50002 - Overview

The Osprey MVS-8 is an 8 Channel Rackmount Monitor supporting 3G-SDI. It also features Audio Bars and Time Code Display. A Windows Software Application enables Brightness and Contrast adjustments as well as custom display overlay.

  • Specifications:

    • Display
    • 8x 2" TFT LCD
    • Resolution: 640x240 (supports up to 1920x1080)
    • Aspect Ratio: 4:3
    • Contrast: 300:1
    • Viewing Angle: 80°

      Video Connections (all Full Size BNC)
    • 8x 3G-SDI with Loopouts

      SDI Video Standards (Level A)
    • 525i59.94 NTSC, 625i50 PAL
    • 720p50,59.94,60
    • 1080p23.98,24,25,29.97,30,50,59.94,60
    • 1080psf 23.98,24
    • 1080i50,59.94,60
    • SMPTE SDI Compliance: 125M, 292M, 296M, 372M

      Controls
    • Dip Switch Controls in the Back of the Unit
    • Windows RS422 Control Software

      Power
    • 12-24VDC Power Input
    • Power Requirement: <23W

      Physical
    • 1U 482.5 x 44 x 104.7mm
    • Weight: 1.6kg
    • Operating Temperature: 0C to 40C
    • Non-Operating Temperature: -20C to 60C


  • Item Includes:

    • 1x MVS-8 Monitor
    • 1x Power Supply
    • 1x RJ12 to DB9 RS422 Adapter


  • Warranty:

    • 1 Year


  • GTIN:

    0850189006979
