Blackmagic Design URSA Studio G2 7 Inch 1920 x 1200 Viewfinder - B-Stock (Open&Used/Warranty)

ITEM #: BMDCINEURSNSVF2B MFG #: BMDCINEURSNSVF2B

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the BMDCINEURSNSVF2B

BMDCINEURSNSVF2B - Overview

This used URSA Studio Viewfinder gives you everything you need to comfortably operate your URSA Mini in live production! The bright 7" screen has a detachable sunshade and includes large handles and an articulated pivot mount that let you position and move the viewfinder independent of the camera!

The large rotary control dials and customizable function buttons let you make on the fly adjustments without having to take your eyes off the action! Set up is quick and easy using the included V-Lock plate and it connects directly to the SDI monitor and power output on your URSA Mini, so you don't need additional cables or power supplies.

Please Note: This is a B-Stock item. This viewfinder was opened/used and is still under warranty. The box it was returned in has the wrong serial number.

  • Features:

    • Controls
    • Dial, knobs and customizable function buttons for settings, short cut features and navigating menus.

      Handles
    • Built in grab handles for positioning the monitor independently from the camera.

      Position Adjustment Options
    • Variable tension pivot points for articulated arm and grab handles with forward, backward, up, down, pan and tilt adjustments.

      Mounting Options
    • Quick release V-lock mounting bracket for attaching viewfinder to URSA Mini handle.

      Tally
    • Large LED tally light with customizable perspex camera numbers.

      Metadata Support
    • Detects camera information embedded in the SDI signal including status information, frame guides, focus peaking, tally, and more.

      Screen Interface
    • On screen meters and status information including Camera ID, resolution, frames per second, shutter speed, gain, white balance, camera battery level, and more.

    • Please Note: This is a B-Stock item. This viewfinder was opened/used and is still under warranty. The box it was returned in has the wrong serial number.

  • Specifications:

    • Connections
    • SDI Video Input: 1 x HD/Ultra HD 3G-SDI via BNC.
    • Power Input: 1 x 4 pin XLR 12V
    • Screen Dimensions: 7" 1920 x 1200 resolution
    • Screen Type: 7" high brightness TFT LCD
    • Screen Brightness: 2000 nits

    • Computer Interface:
    • 1 x USB type C connector for initial setup and software updates via Blackmagic Camera Setup software.

      SDI Video Standards
    • HD Format Support:
      720p50, 720p59.94, 720p60
      1080p23.98, 1080p24, 1080p25,
      1080p29.97, 1080p30, 1080p50,
      1080p59.94, 1080p60
      1080i50, 1080i59.94, 1080i60
    • SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE, 296M, SMPTE 425M 2084.
    • Video Sampling: 4:2:2 YUV.
    • Color Precision: 10-bit.
    • Color Space: REC 601, REC 709.
    • Multiple Rate support: SDI switches between 1.5 Gb/s HD and 3.0 Gb/s 60P HD.

  • Item Includes:

    • 1x Blackmagic URSA Studio Viewfinder G2

  • Warranty:

    • 12 Month Limited Manufacturer's Warranty

  • GTIN:

    9338716007695
